Drake meme. Throwing an exception for every way a payment can fail / A sealed interface the compiler won't let you forget

Source: github.com/rishabh0111/nostro-ledger. docker compose up --build starts all three services with two demo tenants and their API keys printed to the console, and the README walks from there to a refused cross-tenant write in six requests. Its 25 claims each name the test that proves them, and CI ticks that list from the test reports on every push.

Two requests arrive at the same moment. Both want to take 5.00 out of an account that holds 5.00.

The obvious Java reads the balance, checks it is at least 5.00, and saves the new one. Run that twice in parallel and both requests read 5.00, both pass the check, and both save. The account now holds -5.00. Nobody got an exception, and the tests passed, because the tests send one request at a time.

That race is the kind of question a backend interview is really asking, and a CRUD demo never has to answer it. So I built a Java project that has to answer all of them:

  • What happens when two requests race for the same row?
  • When the network drops a response and the client retries?
  • When Kafka delivers a message twice, or a slow transaction commits out of order?
  • When a request from one tenant names another tenant’s data?
  • What does the compiler catch, and what only shows up in production?

Nostro is a multitenant double-entry ledger with an HTTP API. Money is the domain because it punishes every one of those mistakes, and a ledger can get money wrong in four ways: record a movement that does not balance, lose one, apply one twice, or let one tenant see or touch another’s money. I wanted each of them to be impossible rather than unlikely. What it adds up to:

  • Three Spring Boot 4 services on Java 21 from one ten-module Maven reactor: an HTTP API, a Kafka outbox relay, and a gRPC projection service with its own database.
  • Failure modes as types. Every refusal is a record in a sealed interface, mapped to an RFC 9457 response by an exhaustive switch. A new failure without a response does not compile.
  • Concurrency that holds under load. 32 concurrent writers on one hot account in a Gatling run: zero deadlocks, zero serialization failures, zero lock timeouts.
  • Exactly-once effects on at-least-once delivery: idempotency keys in the same transaction as the write, a single-writer relay with leader failover, and a projection that halts rather than skip a message.
  • Tenant isolation through every layer: Spring Security derives the tenant, Hibernate 7 carries it on the right connection, gRPC metadata passes it between services, and Postgres enforces it.
  • 211 tests on every push, 127 of them against real Postgres, Kafka and Redis in Testcontainers, in a CI run of under three minutes.

This post walks through the decisions behind each of those, including the ones I rejected.

The shape of it

flowchart TB
    Client([Client<br/>API key or JWT]) -->|POST /v1/entries| API[API service<br/>scales out]
    API -->|rate limit| Redis[(Redis)]
    API -->|Entry + outbox row<br/>one transaction| LDB[(Ledger<br/>Postgres)]
    Relay[Outbox relay<br/>one writer] -->|drains| LDB
    Relay -->|by tenant| Kafka[(Kafka)]
    API -.->|GetBalance, gRPC| Proj[Projection<br/>service]
    Kafka --> Proj
    Proj -->|applied once| PDB[(Projection<br/>Postgres)]
    classDef actor fill:#DBEAFE,stroke:#2563EB,stroke-width:2px,color:#1E3A8A
    classDef gateway fill:#EDE9FE,stroke:#7C3AED,stroke-width:2px,color:#4C1D95
    classDef service fill:#D1FAE5,stroke:#059669,stroke-width:2px,color:#065F46
    classDef store fill:#CFFAFE,stroke:#0891B2,stroke-width:2px,color:#164E63
    class Client actor
    class API gateway
    class Relay,Proj service
    class LDB,PDB,Kafka,Redis store

The vocabulary matters, so here it is once. An Entry is one balanced movement of money. It is made of Postings, each a signed amount against one Account, and the Postings of an Entry sum to zero in every currency they touch. A Tenant owns Accounts and can never see anyone else’s. I refused to call an Entry a “transaction”, because this design leans on database transactions constantly, and “the transaction is recorded in one transaction” is a sentence that is both true and useless.

Writes go to the API service, which records the Entry and an outbox row in the same database transaction. A relay drains the outbox into Kafka. A projection service consumes Kafka into Balances in a database of its own, and the API asks it for a Balance over gRPC. Redis holds per-tenant rate limits and nothing else.

The code is split the same way. nostro-domain is plain Java with no Spring and no database: the Entry rules, the money arithmetic and the outcome types, tested with JUnit 5 and AssertJ without starting anything. Persistence, the outbox, the gRPC contract and shared test fixtures are modules of their own, and each of the three services depends on only what it uses. It is about 6,800 lines of main Java and 6,300 lines of test Java.

The stack is current on purpose: Java 21, Spring Boot 4.1 on Spring Framework 7, Hibernate ORM 7, Spring gRPC, the plain Kafka Java client, Flyway, Micrometer Tracing, springdoc OpenAPI, and virtual threads on in the API service.

Decision 1: a refusal is a value, and the compiler checks every one is handled

An unbalanced Entry, a breached floor or a reused idempotency key is not an exceptional event in a ledger. It is an answer the caller needs. So recording an Entry returns a value, and the domain models every refusal as a record in a sealed interface:

sealed interface Refused extends RecordOutcome
        permits Unbalanced, UnknownAccount, CurrencyMismatch, InsufficientBalance,
                IdempotencyKeyReused, UnknownEntry, AlreadyReversed {
}

One switch maps every refusal to an RFC 9457 Problem Details response, with no default branch. Because the switch is exhaustive over a sealed type, adding a refusal without deciding its HTTP response is a compile error, not a 500 somebody finds in production. A test pins each case to its status and problem type, and another asserts that the whole catalogue appears in the generated OpenAPI document. Even the framework’s own refusals, a malformed body or a missing credential, come back in the same shape.

The same idea runs past the compiler, into startup. Three mistakes stop the application from starting rather than failing on the first unlucky request:

  • An endpoint with no permission declared. Every handler states the permission it needs, and Spring Security enforces it. One that declares none fails the boot.
  • A Kafka producer setting that would break ordering. The relay’s ordering depends on idempotent, in-order delivery, and a configuration that quietly weakens that fails at startup.
  • A Kafka topic with the wrong shape. The partition count decides where each Tenant’s Entries land, so the relay creates the topic itself and refuses to start on one with a different count.

A failure at startup cannot hide on an untested path. Each of the three has a test.

Decision 2: the race is settled by the row lock, not by a check in Java

Back to the two withdrawals. An Account can be declared constrained when it is created, meaning its balance may never go below zero. Any check in Java has the same problem: it holds only for the code paths that remember to perform it, and even those race each other. I looked at three ways to hold the line.

SUM() under SELECT ... FOR UPDATE. Lock the Account, add up its history, compare. It is correct, and its cost grows with every Posting the Account has ever had.

SERIALIZABLE isolation. The database detects the conflict and aborts one transaction. Also correct, and under contention on a hot account it produces retry storms, which is exactly the workload the floor exists for.

A stored balance, moved by a guarded UPDATE. This is what I built:

UPDATE account
   SET balance_minor = balance_minor + :delta
 WHERE tenant_id = :tenant AND id = :account
   AND (NOT constrained OR balance_minor + :delta >= 0)

The UPDATE takes the row lock and checks the floor in one statement. The second writer waits for the first to commit, re-evaluates the predicate against the new balance, and updates zero rows. The Java side reads zero rows as InsufficientBalance, one of the sealed refusals above, and the API answers 422. No exception is involved. A CHECK constraint on the column is the backstop, for any future UPDATE that forgets the predicate.

The Java around that statement is where the rest of the concurrency work lives:

  • Locks are taken in a fixed order. An Entry that touches two constrained Accounts updates them sorted by id, so two Entries moving money in opposite directions can never deadlock. A test runs exactly that, and another puts 40 concurrent writers on one Account and checks the only refusals are the floor.

  • Retries are for transient failures only. Serialization failures, deadlocks and lock-not-available (SQLSTATE 40001, 40P01, 55P03) are retried with Spring Framework 7’s core RetryTemplate:

    this.transientFailures = new RetryTemplate(RetryPolicy.builder()
        .predicate(SqlFailure::isTransient)
        .maxRetries(3)
        .delay(Duration.ofMillis(25))
        .multiplier(2.0)
        .maxDelay(Duration.ofMillis(400))
        .jitter(Duration.ofMillis(25))
        .build());

    A floor refusal is never retried: it is an answer, not a failure.

  • Unconstrained Accounts take no row lock at all. They carry no stored balance, so their writes are pure inserts. Only Accounts that asked for a floor pay for one.
  • The request path has hard limits: a 1-second lock_timeout and a 3-second statement_timeout on its database role, so a stuck lock becomes an error instead of a hung thread.

The rule that took me longest to accept: a reversal is subject to the floor too, so a correction can be refused. An exemption cannot be written as a database constraint, so granting one would have moved the invariant back into application code, the thing this decision exists to avoid.

A balanced Entry is enforced the same way. The domain refuses an unbalanced Entry as a value, and a deferred constraint trigger re-checks every Entry’s Postings per currency at COMMIT, so even raw SQL cannot commit one. Entries and Postings are insert-only for the application’s role.

Decision 3: idempotency is a unique index inside the same transaction

A client sends an Entry, the network drops the response, and the client retries. Without idempotency that is a duplicate payment.

The common designs put an idempotency record in Redis, or model a little state machine: pending, then complete, with timeouts for requests that died halfway. I did neither. The idempotency record holds the key, a SHA-256 fingerprint of the request body, and the response to replay. It is written in the same transaction as the Entry, under a unique constraint on (tenant_id, idempotency_key).

That removes the in-flight state entirely. A duplicate that arrives while the original is still open blocks on the unique index until the original commits. It then fails the constraint, reads the stored response, and returns it verbatim. A test fires concurrent duplicates and checks that exactly one Entry exists afterwards.

Three smaller choices follow from that:

  • The key is required. An optional key means the duplicate-payment hole is on by default.
  • The same key with a different body is a loud 422. Replaying the old response to a different request would be a silent lie, and the fingerprint exists to catch it.
  • Redis must not hold these keys. Redis cannot join the Entry’s transaction, so moving the key there turns a guarantee back into a race.

Decision 4: the tenant comes from the credential, through every layer

A caller’s Tenant is derived by Spring Security from the API key or the 15-minute staff JWT they present. It is never a header, a path segment or a body field, so there is nothing for a caller to change. Postgres then enforces it twice: row-level security on every tenant-scoped table, and composite (tenant_id, id) foreign keys, so a Posting cannot reference another Tenant’s Account even if row-level security were somehow off. I wrote about those database mechanics in an earlier post. The traps that were new here were all in the Java layers above it.

Hibernate 7 has to use the transaction’s connection. Row-level security reads the Tenant from a transaction-local setting on the connection. I used Hibernate’s StatelessSession for the write path, and if that session ever opened its own connection it would have no Tenant set, and every query would quietly return nothing. Spring’s source suggested the session shares the transaction’s connection, but no document promised it. So the first thing I built was a test that compares pg_backend_pid() across both paths. It still runs in CI, next to another that proves nothing in the request path borrows a second connection inside a transaction.

Hibernate 7 turns the second-level cache on for stateless sessions by default. A cached entity outlives the Tenant context that was allowed to load it, so that default would have undone the isolation work without a single error. The cache is off, explicitly, with a comment saying why.

gRPC carries the Tenant in call metadata, and the projection applies the same row-level security to its own database. The isolation test runs over a real socket, because gRPC’s in-process transport skips metadata serialization, and metadata is exactly what carries the Tenant.

Another Tenant’s Account answers 404, never 403. A 403 confirms the Account exists.

Decision 5: every Balance says how stale it is

Balances are served from the projection, which lags the write by however long the relay and Kafka take. Serving a lagging number as if it were current would be a lie. So every Entry returns a Position when it is recorded, and every Balance reports the Position it reflects. A caller that needs to read its own write passes that Position back as minPosition, and the read waits for it, up to a server-side cap.

The hard part was choosing what a Position is.

A bigserial column looks perfect, and it is broken for this. Sequence values are assigned when a transaction first writes, not when it commits. Transaction A takes value 10 and is slow. Transaction B takes 11 and commits first. A reader tailing by sequence sees 11, moves past it, and never goes back for 10. Nothing errors and nothing rolls back. One Entry never reaches the projection, and every Balance after it is wrong.

sequenceDiagram
    autonumber
    participant A as Entry A
    participant DB as Postgres
    participant R as Relay
    A->>DB: gets Position 10
    Note over DB: Entry B gets 11<br/>and commits first
    R->>DB: committed?
    DB-->>R: 11 (10 open)
    Note over R: publish 11,<br/>move on
    A->>DB: COMMIT
    Note over A,R: 10 commits behind<br/>the watermark and<br/>is never published

The Position is the transaction’s xid8, prefixed with the database’s system identifier, so a token from a different database fails loudly instead of comparing as a plausible number. The relay publishes a row only once its Position is below the oldest transaction still open:

SELECT ...
  FROM outbox o
 WHERE o.published_at IS NULL
   AND o.position < pg_snapshot_xmin(pg_current_snapshot())
 ORDER BY o.position
 LIMIT ?

Below that line, every transaction has either committed or rolled back, so nothing can appear later underneath what the relay has already published. Publish order becomes exactly Position order, and there is a test in which a late committer is never overtaken.

The read contract got as much thought as the token. A minPosition read always answers 200 with the Position it actually reflects, even when the wait timed out. The caller asked for freshness, can see whether they got it, and decides. And the service releases its JDBC connection before it parks the request to wait. If it held the connection, a lagging projection would drain the Hikari pool, and the freshness feature would become an outage under exactly the conditions it exists for. There is a test for that too, on both sides of the gRPC call.

Decision 6: three services, because two replica counts conflict

I did not split this into services for style. The relay has to be a single writer, because publishing in Position order needs one reader of the outbox. SKIP LOCKED, the usual trick for parallel queue consumers, reorders rows by design. The API has to scale out horizontally, with every instance drawing on one shared per-tenant rate limit in Redis. One process cannot run one replica and many replicas at the same time.

So there are three Spring Boot applications from one Maven reactor. The relay elects its writer with pg_try_advisory_lock on the connection that drains, so if the leader dies its session ends, the lock goes with it, and a standby takes over. There is a test that kills the leader mid-drain and checks that nothing is lost or reordered.

I did not split reads from writes. They have no different scaling need, and it would have doubled the authentication code for nothing.

Decision 7: the Kafka consumer stops instead of lying

Kafka redelivers, so applying an Entry has to be idempotent. The projection writes an applied_entry row, unique on Entry id, in the same transaction as the Balance update, and stores the consumed offset with that same write. Kafka’s exactly-once semantics do not cover a consumer writing into an external database, which is what this is, so I do not rely on them. The test publishes every Entry twice, then replays the whole topic from offset zero, and checks that each Tenant’s Balances still sum to zero.

The more interesting decision is what happens to a message the projection cannot apply. The reflex answer is a dead-letter topic. For a ledger that is the wrong answer. Skipping one Entry means serving a wrong Balance to everyone, indefinitely, while the dead-letter topic makes the problem look handled. So the consumer pauses that partition, seeks back to the failed record, and raises a metric immediately. A halted ledger pages someone. A ledger that skips an Entry keeps serving wrong balances, and nobody finds out.

Decision 8: each piece of infrastructure has to earn its place

Kafka, Redis and gRPC are what Java backend teams run in production, and that makes it easy to add them without a reason. So I set a rule: at most one of them may be justified as generic infrastructure, and the other two have to answer a need the ledger actually has.

  • Kafka is the replayable log between the write model and the read model. A projection polling Postgres could not rebuild from zero without loading the write database, or add a second consumer without a second poller. The relay uses the plain Kafka Java client, keyed by Tenant over 12 partitions, so each Tenant’s Entries stay in order.
  • gRPC is how the API asks the projection for a Balance: internal, frequent, typed by a Protobuf contract in its own module, and it carries the Position back with the answer. Each call has a deadline and bounded retries on UNAVAILABLE and DEADLINE_EXCEEDED.
  • Redis holds per-Tenant rate limits through Bucket4j, because a limit shared across API instances cannot live in one process. This is the one generic justification, and it is at least the relevant kind: one noisy tenant starving the others is this project’s actual subject.

Two things I decided not to build: a balance cache and a circuit breaker.

Redis must not cache Balances. It would be a third source of truth next to the stored balance and the projection, it would need Position semantics of its own, and a cached value outlives the Tenant context that authorized loading it.

The one remote call gets a timeout and bounded retries, and no circuit breaker. A breaker is worth as much as the fallback it enables, and there is no honest fallback for a Balance. The stronger argument is that the write path never calls the projection at all. The floor check runs on the stored balance in the API’s own database, so if the projection is down, reads fail and money can still be recorded correctly.

How 211 tests keep the claims honest

A design like this is only as good as the evidence that it still holds after the next change, so the tests got as much design as the services.

  • Real infrastructure, not mocks. 127 integration tests run against Postgres, Kafka and Redis in Testcontainers 2, using the same image tags as docker compose, so CI exercises what a developer runs locally. Each module’s suite shares one container per dependency, and Awaitility waits on the asynchronous paths instead of sleeping.
  • One Spring context per deployable. The context cache is the cost that grows without bound as a Spring suite grows, so each service’s tests share a single configuration, and CI publishes the cache statistics to prove it. In the latest run, every module built exactly one context.
  • Three parallel jobs. The domain and unit tests come back in under a minute without waiting on containers. The integration suites run each service at its own seam. An end-to-end job runs the real docker compose up --wait and follows one Entry through every service. The whole pipeline takes under three minutes.
  • The README is under test. Its 25 claims each name a test method. ReadmeClaimsTest checks that every named file and method really exists, and a CI step ticks each claim from the test reports into the run summary. The script that does the ticking has tests of its own.

The result is a README that cannot drift from the code without the build going red.

What one hot account costs

I load-tested it with Gatling on my laptop, against the compose stack: 32 concurrent writers for 60 seconds per arm. In the contended arm every request hits one constrained Account. In the spread arm the same load goes across 64 Accounts. Each Account starts with 5.00 and the requests random-walk it, so the floor keeps refusing throughout.

  One hot Account Spread over 64
Requests 6,346 12,769
Throughput 105.8/s 212.8/s
p50 275 ms 142 ms
p99 741 ms 320 ms
Refused at the floor 35 324
Anything else 0 0

The claim was never the throughput number, which is specific to one laptop running everything at once. The claim is the last row. Across both arms the ledger met no database error of any SQLSTATE: no deadlock, no serialization failure, no lock timeout, no 5xx. Every refusal was the floor, and the server’s own Micrometer counter matched the clients’ count exactly, 359 = 35 + 324. One hot row costs half the throughput and 2.3 times the p99, and nothing fails to pay for it.

I recorded the API service with JFR over the whole run. It was not CPU-bound: no method held more than 3% of samples, and GC paused for 1.44 s in total over 162 s. The time went to waiting on the database, and mostly on the Hikari pool rather than the row lock. That looks like a reason to raise the pool size from its default of 10, and the arithmetic says not to. At 105.8 commits per second the hot row is held for about 9.5 ms at a time, so ten queued transactions wait at most about 95 ms for it, well inside the 1-second lock_timeout. Thirty-two connections would move 22 more waiters from Hikari’s queue, where waiting is free, into Postgres’s lock queue, where each waiter holds a backend and an open transaction, for no extra throughput. The row serializes them either way.

JFR also left two leads I have not chased yet: something reflects on every request, and both Jackson 2 and Jackson 3 serialize at runtime, so some dependency still pulls in the old line. The full notes, with the raw data and the JFR views, are in the repo.

What I left out on purpose

  • Holds and reservations. They are a real two-phase concept, and they would roughly double the balance model (available versus posted) and add expiry, which means a scheduler.
  • “Balance as of time T”. A running projection cannot answer it, and a SUM over history can, which brings back the mechanism Decision 2 rejected.
  • Change data capture with Debezium. Its ordering is documented, which is a real advantage over my hand-written relay. It also adds logical replication, a replication slot that can fill a disk, and a Kafka Connect worker to a stack whose whole point is docker compose up. If the ordering requirement ever hardens to global commit order, that is the migration, and I would make it.
  • Deployment. No Kubernetes and no cloud. The problems worth showing are in the types, the concurrency and the service boundaries, and none of them needs a cluster. My DevOps platform post is where the cluster work lives.

What I would tell myself at the start

  1. Model failure as data. A sealed type of refusals turns “did we handle every case?” from a code review question into a compiler error.
  2. Put every invariant where the least disciplined code path still hits it. For money, that is the schema. Application checks are for good error messages.
  3. Find out what your ordering number actually means. “Assigned in order” and “committed in order” are different promises, and the difference loses data without an error.
  4. Refuse loudly. A halted partition, a failed boot and a compile error are all cheaper than a wrong balance that nobody notices.
  5. Make the claims checkable. A README that names a test for every claim, parsed by a test and ticked by CI, cannot drift from the code without the build going red.

Project at a glance


Stack Java 21, Spring Boot 4.1 (Spring Framework 7), Spring Security, Hibernate ORM 7, Spring gRPC, Kafka 4, Postgres 16, Redis 7 + Bucket4j, Flyway, Micrometer, Maven
Services API service, outbox relay, projection service, from one ten-module Maven reactor
Guarantees balanced Entries, a schema-enforced floor, at-most-once recording, at-most-once projection, tenant isolation through every layer
Tests 211 on every push (82 unit, 127 Testcontainers integration, 2 end to end), JUnit 5, AssertJ, Awaitility; CI under three minutes
Proof 25 README claims, each naming its test, ticked by CI from the test reports
Load test Gatling with JFR: 32 writers on one hot account, 6,346 requests, zero database errors
Code github.com/rishabh0111/nostro-ledger

Built and written by Rishabh Sharma. The decisions above, and eight smaller ones, are written up one per file, each with the options it rejected, in the repo’s docs/adr/.
